MOXIN S801100 Controller - (Anti-Loop)

Name: MOXIN S801100 Controller - (Anti-Loop)
Brand: PowerRide
SKU: 191286130:-4#60000W;210188692:-2#controller;210190015:3327837#Black
Price: 1100.0 USD
Availability: InStock

$1,100.00

Shipping calculated at checkout.

Wattage

60000W

Motor Type

controller

Color

Black

[{"id":43813105238095,"title":"60000W \/ controller \/ Black","option1":"60000W","option2":"controller","option3":"Black","sku":"191286130:-4#60000W;210188692:-2#controller;210190015:3327837#Black","requires_shipping":true,"taxable":true,"featured_image":{"id":41349749964879,"product_id":7907594043471,"position":1,"created_at":"2025-11-17T23:42:07-05:00","updated_at":"2025-11-17T23:42:09-05:00","alt":null,"width":1500,"height":1500,"src":"\/\/qz06sv-zf.myshopify.com\/cdn\/shop\/files\/Hf3855146c9124ebd87c4a3f6d08ae9b4d.webp?v=1763440929","variant_ids":[43813105238095]},"available":true,"name":"MOXIN S801100 Controller - (Anti-Loop) - 60000W \/ controller \/ Black","public_title":"60000W \/ controller \/ Black","options":["60000W","controller","Black"],"price":110000,"weight":6000,"compare_at_price":90099,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":null,"id":32950911139919,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/qz06sv-zf.myshopify.com\/cdn\/shop\/files\/Hf3855146c9124ebd87c4a3f6d08ae9b4d.webp?v=1763440929"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":43813105238095,"title":"60000W \/ controller \/ Black","option1":"60000W","option2":"controller","option3":"Black","sku":"191286130:-4#60000W;210188692:-2#controller;210190015:3327837#Black","requires_shipping":true,"taxable":true,"featured_image":{"id":41349749964879,"product_id":7907594043471,"position":1,"created_at":"2025-11-17T23:42:07-05:00","updated_at":"2025-11-17T23:42:09-05:00","alt":null,"width":1500,"height":1500,"src":"\/\/qz06sv-zf.myshopify.com\/cdn\/shop\/files\/Hf3855146c9124ebd87c4a3f6d08ae9b4d.webp?v=1763440929","variant_ids":[43813105238095]},"available":true,"name":"MOXIN S801100 Controller - (Anti-Loop) - 60000W \/ controller \/ Black","public_title":"60000W \/ controller \/ Black","options":["60000W","controller","Black"],"price":110000,"weight":6000,"compare_at_price":90099,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":null,"id":32950911139919,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/qz06sv-zf.myshopify.com\/cdn\/shop\/files\/Hf3855146c9124ebd87c4a3f6d08ae9b4d.webp?v=1763440929"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

MOXIN - SPECIFICATIONS

Frame Material: aluminum alloy

Motor Power: 60KW

Part: controller

Protective Feature: waterproof

Rated Power: 60KW

Voltage: dc 80v

Wheel Material: aluminum

Product Description

Specification

Model	S801100
Rated voltage	48V-80V
Actual input voltage	40V-94V
Rated power	16kW
Peak phase current	1100A
Continuous bus	500A (heat dissipation)
Peak power (10s)	80V* 770A=61.6kW
Dimensions	281mm98mm63mm
Weight	2.8kg
Power tubes	30 tubes of TOLL
SC current	±1500A, response time 5us
Regen method	throttle recovery/ brake power-offrecovery/ linear electronic braking
Max speed	200,000 RPM (1 pair )50,000 RPM (4 pairs )12,500 RPM (16 pairs )
Waterproof	10M water resistant, high pressure water gun protection
Working temp	Normal operating temperature range-40°C~75°C, over 75°C quickly reduce the current
Work efficiency	Typical value 99%, efficiency above 96% at peak power (test condition: 100% throttle)
Motor compatibility	Accurate motor self-learning algorithm, one-click identification of parameters
Ctrl response time	Respond 1000 times per second with a delay of lms
